QUICK START
DUT OUTPUT: ON
a). Unpack this instrument from its special shipping container.
b). Locate a suitable testing area and be sure you have read all
safety instructions for the operation of the instrument and
suggestions on the test area set-up in the SAFETY section of this
manual. Locate a three prong grounded outlet. Be sure the outlet has been tested for
proper wiring before connecting the instrument to it.
c). Check to be sure the correct input line voltage has been selected
on the rear panel. Either 115 volts AC or 230 volts AC. Connect
the power input plug into its socket on the rear panel of the
instrument. Connect the male end of the plug to the outlet receptacle.
Please be sure that the safety ground on the power line cord is not defeated and
that you are connecting to a grounded power source.
d). Turn on the POWER switch located on the lower left hand side of the front panel.
Upon powering the instrument up a POWER ON SELF TEST (POST) will automatically
be performed. This test will check for the condition of the ram chips, pcb's and other
critical components. In addition, you will see the Slaughter Company name, Model
Number, and current software version briefly appear on the LCD readout and then clear
itself.
You should then see the default parameters on the LCD meter as follows:
These abbreviated parameters stand for the following:
1 - 1: Indicates the memory and step location of the current settings.
Set: This is the parameter settings review screen
1.0s: The dwell timer is set to a test duration of 1 second.
1.24kVAC: The test voltage is set to 1,240 volts AC.
10.00mA: The high leakage current trip point is set to 10 milliamps.
If you wish to not use any one of these parameters you must change your parameters.
Please refer to the Operation Instructions section in this manual for further details.
e). If the instrument defaults are acceptable then be sure to connect the appropriate test
leads to the device under test (DUT) or test fixture. Be sure to connect this safety ground
ACW Set 1.0s
1-1 1.24kV 10.00mA
