OPERATION
6.5. To set the DUT OUTPUT ON
Press the SET key until the display shows:
Press the Up () or Down () arrow keys to toggle the DUT OUTPUT mode to ON or
OFF, then press the SET key to advance to the first parameter or press the EXIT key to
store the setting and return to the test mode. If DUT OUTPUT is set to ON the Output
Power connections will become live during testing. These terminals may be used to apply
high voltage to the DUT from the rear panel. If DUT OUTPUT is set to OFF voltage and
current will only be present on the front panel connections.
6.6. To set the Connect mode ON/OFF
Press the SET key until the display shows:
Press the Up () or Down () arrow keys to toggle the connect mode to ON or OFF, then
press the SET key to advance to the next parameter or press the EXIT key to store the
setting and return to the test mode. If Connect is set to ON the next step in the sequence
will be executed. If Connect is set to OFF the test sequence will stop at this step. If step
10 is set to ON the test process will be connected to the first step of the next memory.
Step 10 of the memory 20 does not have Connect ON/OFF option.
7. GND Bond test mode setting
7.1. To set the Output Current
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to enter the desired output current setting, then
press the SET key to advance to the next parameter or press the EXIT key to store the
current setting and return to the test mode. The unit of measure is in amperes with 3A –
30A range of setting. Any attempt to set the value outside these limits will cause the
instrument to indicate an ERROR message by producing two short beeps.
7.2. To set the High or Low Limits
Press the SET key until the display shows:
