OPERATION
0.5 seconds. The maximum delay time setting is 999.9 seconds. Any attempt to set the
value more than 999.9s or less than 0.0s will cause the instrument to indicate an ERROR
by producing two short beeps.
Note: The Delay timer in the Line Leakage mode differs from the Dwell timer in the
Hipot mode. A judgment is not made until the Delay time has elapsed. Therefore, when
the Delay time is set to zero Pass and Fail judgment or indications will not be made.
9.6. To set the Connect mode ON/OFF
Press the SET key until the display shows:
Press the Up () or Down () arrow keys to toggle the connect mode to ON or OFF, then
press the SET key to advance to the next parameter or press the EXIT key to store the
setting and return to the test mode. If Connect is set to ON the next step in the sequence
will be executed. If Connect is set to OFF the test sequence will stop at this step. If step
10 is set to ON the test process will be connected to the first step of the next memory.
Step 10 of the memory 20 does not have Connect ON/OFF option.
10. System Menu Parameters Setting
10.1. To set the PLC Remote ON/OFF
Press EXIT key once. The display shows:
Use the Up () or Down () arrow keys to change the PLC Remote setting, then press the
SET key to advance to the next parameter or press the EXIT key to store the setting and
return to the test mode. When the PLC Remote is turned ON the front panel TEST button
is disabled and a test may only be started through the rear panel I/O. If you attempt to
start a test from the front panel TEST button when the PLC Remote function is turned
ON the instrument will produce two short beeps and the following pop-up message will
be displayed:
Message will disappear after a few seconds or it can be cleared with the RESET button.
10.2. To set the Single Step ON/OFF
Press EXIT key once then press the SET key until the display shows:
