CALIBRATION
88
Then press the TEST button on the front panel and the display will show:
Then press SET key to advance to the next calibration point or press the RESET button to
return to the calibration menu without changing the calibration setting. Press the EXIT
key to exit from the calibration mode and to return to the test mode.
22. To calibrate the Line Leakage MDC
Please connect a standard current meter and DC power supply in series with the DUT
Power Input terminals. Place the power supply’s positive output (+) to the instrument’s
Neutral terminal. Place the power supply’s negative output (-) to the instrument’s Ground
terminal. Set the power supply to 2.2VDC.
Press the Up () or Down () arrow keys until the display shows:
Then press the TEST button on the front panel and the display will show:
Then press SET key to advance to the next calibration point or press the RESET button to
return to the calibration menu without changing the calibration setting. Press the EXIT
key to exit from the calibration mode and to return to the test mode.
23. To calibrate the Line Leakage MDX
Please connect a standard current meter and DC power supply in series with the DUT
Power Input terminals. Place the power supply’s positive output (+) to the instrument’s
Neutral terminal. Place the power supply’s negative output (-) to the instrument’s Ground
terminal. Set the power supply to 2.2VDC.
Press the Up () or Down () arrow keys until the display shows:
Current = XXXXuA
22. LLT MDC
N/G Input 2.200VDC
Current = XXXXuA
23. LLT MDX
N/G Input 2.200VDC
