Slaughter 6330 - Replacement Parts List

CALIBRATION
90
Replacement Parts List
Model 6330
Rev: G 10/10/2014 ECO 5598-4, ECO5732
Part Number
Qty.
Ref. Designator
Description
Supplied Accessories
99-10460-01
1
OPTIONAL
3U Rack Mount Hardware
99-10106-01
1
-
Fuse 6.3A 250V Slow-Blow 20mm
102-055-913
1
-
High Voltage Cable
125-013-001
1
-
Cable Input Cord set USA
99-10040-01
1
-
Interlock Connector
99-10467-01
1
-
Adapter Box
99-10457-01
1
LLT CASE LEAD
Cable Assembly High Current Lead
99-10468-01
1
LLT GROUND
LEAD
Cable Assembly Ground Lead
99-10009-01
1
GND BND
OUTPUT
Cable Assembly High Current Output
99-10008-01
1
RETURN LEAD
Cable Assembly High Current Return
99-10469-01
1
LLT INPUT LINE
LLT DUT Input cable LINE
99-10470-01
1
LLT INPUT
NEUTRAL
LLT DUT Input cable NEUTRAL
99-10471-01
1
LLT OUTPUT
LINE
LLT DUT HV Output Cable Line
99-10472-01
1
LLT OUTPUT
NEUTRAL
LLT DUT HV Output Cable Neutral
99-10573-01
1
-
RS232 Cable
Panel Components
99-10018-01
2
-
High Voltage Connector
99-10312-01
1
-
Power Switch 2P 15A/250V
99-10016-01
1
-
Earth Connector
330-113-001
1
TEST
Test Switch Green Lighted
330-113-002
1
RESET
Reset Switch Red Lighted
99-10046-01
1
-
HV Indicator LED
175-946-013
1
-
Feet Kit w/o Rubber Inserts
175-974-002
4
-
Rubber Insert for Feet
99-10618-01
1
-
20 x 2 LCD Display
99-10673-01
2
-
Binding Post 30 Amp Red
99-10674-01
2
-
Binding Post 30 Amp Black (Return)
99-10671-01
1
TEST/PASS
Replacement Bulb
99-10672-01
1
RESET/FAIL
Replacement Bulb
PCB Assemblies
99-10222-01
1
CKB-06
Keypad Board
99-10321-01
1
AMP4320
Amplifier Board
99-10322-01
1
HV4320
High Voltage Control Board
