OPERATION
attempt to set the value above this limit will cause the instrument to signal an ERROR by
producing two short beeps.
5.3. To set the Low Leakage Current Limit
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to enter the leakage current low limit setting,
then press the SET key to advance to the next parameter or press the EXIT key to store
the setting and return to the test mode. The unit of measure is milliamperes with
30.00mA AC and 5.00mA DC as the maximum setting and with 0.00mA AC and DC as
the minimum setting. The Low Leakage Current Limit will act as the low “trip point” for
the Hipot test. If the measured leakage current does not exceed this value, the test will
fail. Any attempt to set the value below this limit will cause the instrument to signal an
ERROR by producing two short beeps.
5.4. To set the Ramp time
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to enter the ramp time setting, then press the
SET key to advance to the next parameter or press the EXIT key to store the setting and
return to the test mode. The minimum ramp time setting is 0.1 seconds, the maximum
ramp time setting is 999.9 seconds. Any attempt to set the values outside these limits will
cause the instrument to signal an ERROR by producing two short beeps.
5.5. To set the Dwell time
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to enter the desired dwell time, then press the
SET key to advance to the next parameter or press the EXIT key to store the setting and
return to the test mode. If the dwell time is set to 0.0s, the instrument will operate in a
continuous ON mode when the TEST button is pressed. The instrument will stop when
the DUT (Device Under Test) goes into failure or the RESET button is pressed. The
actual minimum dwell time setting is 0.2 seconds. The maximum dwell time setting is
999.9 seconds. Any attempt to set the value more than 999.9s or less than 0.0s will cause
the instrument to indicate an ERROR by producing two short beeps.
5.6. To set the Frequency 50/60 Hz (For AC mode only)
Please press the SET key until the display shows:
