Press the SET key until the display shows:
Please use the
Up () or Down () arrow keys to enter the desired value of the High or Low Limits
resistance trip point then press the SET key to advance to the next parameter or press the
EXIT key to store the setting and return to the test mode. The unit of measure is 0 – 10.00
mA. Any attempt to set the value outside these limits will cause the instrument to indicate
and ERROR by producing two short beeps.
9.3. To set the Line Condition
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to select the desired Line Condition. The
available Line Conditions for the Line Leakage test are as follows:
Line
1
2
3
4
5
6
7
8
Neutral
OPEN
OPEN
OPEN
OPEN
CLOSE
CLOSE
CLOSE
CLOSE
Reverse
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Ground
OPEN
OPEN
CLOSE
CLOSE
OPEN
OPEN
CLOSE
CLOSE
As the Line Condition is set, the corresponding LED’s on the front panel will illuminate.
These LED’s will signify which Line Condition is active for the test step. Press the SET
key to advance to the next parameter or press the EXIT key to store the setting and return
to the test mode.
9.4. To set the Measuring Device (MD)
Press the SET key until display shows:
Use the Up () or Down () arrow keys to select the desired Measuring Device. The
available measuring devices are as follows:
Leakage-HI = XXXXuA
or
Leakage-LO =
XXXXuA
Line = 1
MD = A
