Slaughter 6330 - Ground Bond Test Mode

OPERATION
52
2.5. If the insulation resistance does not exceed the low limit setting and is within the
metering range the red RESET button will illuminate and an alarm will activate. The
display will show:
IR LO-Limit
XXX.Xs
XX-XX XXXXV
XXXXMΩ
To stop the alarm, please press the RESET button once. The alarm will stop and the
display will retain the failure information. The instrument is now ready for the next test.
If the RESET button is pressed again, the failure information on the screen will be
cleared and the display will indicate the setting data of the test.
3. Ground Bond Test Mode
3.1. To initiate a test press the TEST button on the front panel. The instrument will
continue to output the desired current for the duration of the selected dwell time. The
display will indicate:
GND Set XXX.Xs
XX-XX XX.XA XXXmΩ
then
GND Dwell XXX.Xs
XX-XX XX.XA XXXmΩ
3.2. If the DUT has passed the test, the green TEST button will illuminate and a short
audible beep will be activate. The display will indicate:
The instrument is ready to perform another test.
3.3. If the operator elects to abort a test in process this can be accomplished by pressing
the RESET button at anytime. The instrument will stop the test process immediately. The
display will indicate:
Please press the TEST button to initiate another test
GND Pass XXX.Xs
XX-XX XX.XA XXXmΩ
GND Abort XXX.Xs
XX-XX XX.XA XXXmΩ
