OPERATION
Press the Up () or Down () arrow keys to toggle the frequency setting to 50 or 60
Hertz, then press the SET key to advance to the next parameter or press the EXIT key to
store the setting and return to the test mode.
5.7. To set the DUT OUTPUT ON
Press the SET key until the display shows:
Press the Up () or Down () arrow keys to toggle the DUT OUTPUT mode to ON or
OFF, then press the SET key to advance to the next parameter or press the EXIT key to
store the setting and return to the first parameter. If DUT OUTPUT is set to ON the
Output Power connections will become live during testing. These terminals may be used
to apply high voltage to the DUT from the rear panel. If DUT OUTPUT is set to OFF
voltage and current will only be present on the front panel connections.
5.8. To set the Connect mode ON/OFF
Press the SET key until the display shows:
Press the Up () or Down () arrow keys to toggle the connect mode to ON or OFF, then
press the SET key to advance to the next parameter or press the EXIT key to store the
setting and return to the first parameter. If Connect is set to ON the next step in the
sequence will be executed. If Connect is set to OFF the test sequence will stop at this
step. If step 10 is set to ON the test process will be connected to the first step of the next
memory. Step 10 of the memory 20 does not have Connect ON/OFF option.
6. IR insulation resistance test mode setting
6.1. To set the Output Voltage
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to enter the desired test voltage, then press the
SET key to advance to the next parameter or press the EXIT key to store the setting and
return to the test mode. The maximum voltage which may be entered is 1000 Volts DC
and the minimum voltage is 100Volts DC. Any attempt to set the value above this limit
will cause the instrument to indicate an ERROR by producing two short beeps.
