The instrument will continue to output the desired voltage for the duration of the selected
Delay and Dwell times. Use the Up () or Down () arrow keys to bring up an alternate
display screen while the test is running. The alternate display screen will show:
4.2. If the DUT has passed the test, the green
TEST button will illuminate and a short audible beep will activate. The display will
show:
Use the Up () or Down () arrow keys to bring up an alternate display screen after the
test has completed. The alternate display will show:
The instrument is ready to perform another test.
4.3. If the operator elects to abort a test in process this can be accomplished by pressing
the RESET button at anytime. The instrument will stop the test process immediately and
the display will show:
Please press the TEST button to initiate another test.
4.4. If the DUT input voltage exceeds the high limit setting or does not exceed the low
limit setting, the red RESET button will illuminate and an alarm will activate. The
display will show:
RUN Volt-HI XXX.Xs
XX-XX XX.XV XX.XA
or
RUN Volt-LO
XXX.Xs
XX-XX XX.XV XX.XA
To stop the alarm, press the RESET button once. The alarm will stop and the display will
retain the failure information. The instrument is now ready for the next test. If the RESET
button is pressed again, the failure information will be cleared and the display will
indicate the setting data of the test.
RUN Set XXX.Xs
XX-XX XX.XV XX.XA
then
RUN Delay XXX.Xs
XX-XX XX.XV XX.XA
RUN Dwell X.XX mA
XX.XX XW
X.XXXPF
RUN Pass XXX.Xs
XX-XX XX.XV XX.XA
RUN Pass X.XX mA
XX-XX XW X.XXXPF
RUN Abort XXX.Xs
XX-XX XX.XV XX.XA
