OPERATION
Use the Up () or Down () arrow keys to enter the desired value of the High or Low
Limits resistance trip point then press the SET key to advance to the next parameter or
press the EXIT key to store the setting and return to the test mode. The unit of measure is
0 – 8400 W. Any attempt to set the value outside these limits will cause the instrument to
indicate an ERROR by producing two short beeps.
8.4. To set the HI and LO Limits (Power Factor)
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to enter the desired value of the High or Low
Limits resistance trip point then press the SET key to advance to the next parameter or
press the EXIT key to store the setting and return to the test mode. Power factor may be
set from 0 – 1. Power factor is indication of how resistive or reactive the DUT is. A
power factor of 1 corresponds to a purely resistive DUT whereas a power factor of 0
corresponds to a purely reactive DUT. Any attempt to set the value outside these limits
will cause the instrument to indicate an ERROR by producing two short beeps.
8.5. To set the HI and LO Limits (Leakage Current)
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to enter the desired value of the High or Low
Limits resistance trip point then press the SET key to advance to the next parameter or
press the EXIT key to store the setting and return to the test mode. The unit of measure is
0 – 10.00 mA. Any attempt to set the value outside these limits will cause the instrument
to indicate an ERROR by producing two short beeps.
8.6. To set the Delay time
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to enter the desired delay time, then press the
SET key to advance to the next parameter or press the EXIT key to store the setting and
return to the test mode. If the delay time is set to 0.0s, the instrument will operate in a
continuous ON mode when the TEST button is pressed. The test will stop only when the
RESET button is pressed or the OFL detected. The actual minimum delay time setting is
0.5 seconds. The maximum delay time setting is 999.9 seconds. Any attempt to set the
value more than 999.9s or less than 0.0s will cause the instrument to indicate an ERROR
by producing two short beeps.
