Slaughter 6330 - Test Parameter Editing Commands

REMOTE BUS INTERFACE: RS-232
68
The parameter values should use complete text and not use the coded values that are
associated with the individual parameter setting commands. Such as "ON" and "OFF"
and any toggle field that use words or phrases like "OPEN", "CLOSE". The LS?
companion command will also list all parameters in complete text as they appear on the
setting screen.
ACW
DCW
IR
1
Voltage
Voltage
Voltage
2
Max Limit
Max Limit
Max Limit
3
Min Limit
Min Limit
Min Limit
4
Ramp Up
Ramp Up
Delay
5
Dwell
Dwell
DUT Output
(ON/OFF)
6
Frequency
DUT Output
(ON/OFF)
Connect (ON/OFF)
7
DUT Output (ON/OFF)
Connect (ON/OFF)
8
Connect (ON/OFF)
GND
RUN
LLT
1
Current
Voltage-HI
Voltage-HI
2
HI-Limit
Voltage-LO
Voltage-LO
3
LO-Limit
Amp-HI
Leakage-HI
4
Dwell
Amp-LO
Leakage-LO
5
Offset
Power-HI
Delay Time
6
Frequency
Power-LO
Line (Neutral,Polarity,Ground)
7
Connect
(ON/OFF)
PF-HI
Meas. Device
(UL544NP/UL484/UL923,UL471,UL867,UL69
7,IEC60990 Fig4 U2,IEC60950-1,IEC60335-
1,IEC60598-1,IEC60065,IEC61010,UL2601-
1,IEC60601-1,External)
8
PF-LO
Delay Time
9
Leakage-HI
Connect
10
Leakage-LO
11
Delay
12
Dwell
13
Connect
(ON/OFF)
Test Parameter Editing Commands
These commands are used to modify the test parameter within each step. These
commands require a parameter value to be included with the command. The companion
query command will read the parameter. The writing of the parameter requires that the
unit not be included with the value, only the numeric value should be included with the
command. Also when the query commands are used the response will not include the
units characters. Many of the commands will function the same way for multiple test
