INSTALLATION
26
Contents of the Carton
Inside the carton should be the following:
Description
SLA Part Number
6330 Compliance Tester
6330 Hipot, Continuity, Ground
Bond, IR, Run and Line Leakage
102-055-913
High Voltage Lead (6ft.)
125-013-001
Input Power Cable (6ft.)
99-10457-01
Cable Assembly High Current
Return Lead
99-10468-01
High Current Output Lead
99-10009-01
High Current Clip with 6 ft Lead
99-10008-01
Ground Return Clip with 6 ft Lead
99-10469-01
LLT DUT Input Cable LINE
99-10470-01
LLT DUT Input Cable NEUTRAL
99-10471-01
LLT DUT HV Output Cable LINE
99-10472-01
LLT DUT HV Output Cable
NEUTRAL
99-10040-01
Interlock
99-10467-01
Adaptor Box
99-10106-01
Fuse
99-10573-01
RS-232 Cable Assembly
*The Line Cord listed is American. Other combinations of the Line Cord are available
upon request.
Only accessories which meet the manufacturer’s specification
shall be used.
Preparation for Use
Power Requirements and Line Voltage Selection
This instrument requires a power source of either 115 volts AC ±
10%, 47-63 Hz single phase or 230 volts AC ±10%, 47-63 Hz
single phase. Please check the rear panel to be sure the proper
switch setting is selected for your line voltage requirements before turning your
instrument on. In addition, please be sure the correct fuse is selected and installed while
the instrument is in the off position.
Do not switch the line voltage selector switch located on the rear
panel while the instrument is on or operating. This may cause
internal damage and represents a safety risk to the operator.
NOTE
For operation at 115 Volts AC and 230 Volts AC use a 6.3 A slow blow fuse.
