Slaughter 6330 - Functional Run;Line Leakage Stand-Alone Test Lead Connections

OPERATION
63
INSTRUMENT CONNECTIONS
The Slaughter 6330 comes with test leads to perform all necessary safety tests. The
following test leads are included with the instrument:
Part Number
Description
99-10467-01
Adapter Box
99-10457-01
LLT CASE LEAD
99-10468-01
LLT GROUND
LEAD
99-10009-01
GND BND
OUTPUT
99-10008-01
RETURN LEAD
99-10469-01
LLT INPUT LINE
99-10470-01
LLT INPUT
NEUTRAL
99-10471-01
LLT OUTPUT
LINE
99-10472-01
LLT OUTPUT
NEUTRAL
102-055-913
High Voltage Cable
Functional Run/Line Leakage stand-alone test lead connections
In order to perform a Line Leakage and/or Functional Run test, an external power supply
must be used to provide power to the device under test.
The power supply must be an unbalanced, single phase 0-277
VAC supply. Using a balanced supply may cause damage to the
instrument or operator.
Provided with the instrument are two 10 AWG input power leads (terminated on one end)
that may be connected to the 6330’s DUT Power In screw-mount terminals (line and
neutral). These leads are left un-terminated at the other end and should be connected to
the outputs of the power supply. The 10 AWG input power leads may be used for
applications in which the DUT requires more than 20 Amps of input current.
Provided with the instrument are two 10 AWG output power leads (terminated on one
end) that may be used to connect to the 6330’s DUT Power Out screw-mount terminals
(line and neutral). These leads are left un-terminated at the other end and should be
connected to the device under test for applications that require more than 20 Amps of
input current
