CALIBRATION
Then press the TEST button on the front panel and the display will show:
Press the Up () or Down () arrow keys to enter the reading of the power meter into the
instrument. Then press SET key to store the current setting and to advance to the next
calibration point or press the RESET button to return to the calibration menu without
changing the calibration setting. Press the EXIT key to exit from the calibration mode
and to return to the test mode
15. To calibrate the Functional Run test leakage current
Please connect a standard Milliammeter to the DUT Power Outputs Line and Ground
terminals. Connect the AC power supply to the DUT I/P of the instrument and set the
voltage to 18VAC.
Press the Up () or Down () arrow keys until the display shows:
Then press the TEST button on the front panel and the display will show:
Press the Up () or Down () arrow keys to enter the reading of the standard AC
Milliammeter into the instrument. Then press SET key to store the current setting and to
advance to the next calibration point or press the RESET button to return to the
calibration menu without changing the calibration setting. Press the EXIT key to exit
from the calibration mode and to return to the test mode
16. To calibrate the Line Leakage test offset
Please disconnect all meters from the instrument.
Press the Up () or Down () arrow keys until the display shows:
14. RUN 8400W
L=10Ω, V=220VAC
15. RUN 10.0mA
DUT I/P=18VAC
