QUICK START
28
QUICK START
This Quick Start Guide assumes the operator has some familiarity with Hipot testing and
desires to use the "default" settings on the instrument. The default settings shown will
remain in memory unless you choose to override them with your own test program. The
instrument default settings are as follows:
DEFAULTS
Input Voltage: 115 or 230 volts AC country specific
(rear panel switch selectable)
System parameters:

PLC Remote: OFF

Single Step: OFF

Fail Stop: ON

Lock: OFF

Memory Lock: ON

Alarm Volume: 5

DUT HV-SET: ON
Test Parameters:

Memory Position: 1

Step Position: 1

Test Mode: AC

Voltage: 1.24 kV

HI-Limit: 10.00 mA

LO-Limit: 0.00 mA

Ramp: 0.1 s

Dwell: 1.0 s

Freq.: 60 Hz

Connect: OFF
