OPERATION
Use the Up () or Down () arrow keys to change the Single Step setting, then press the
SET key to advance to the next parameter or press the EXIT key to store the setting and
return to the test mode.
This function is used to temporarily override the automatic connection feature. When the
Single Step function is ON the instrument will pause after each step is completed, even
though the step Connect function is set to ON. To continue the test sequence, press the
TEST button. Each time the TEST button is pressed the next connected step will execute.
If you press the RESET button before completing all connected steps, it will return the
instrument to the original starting step. If a step fails and you wish to continue to the next
step, do not press the RESET button, press the TEST button.
10.3. To set the Fail Stop ON/OFF
Press EXIT key once then press the SET key until the display shows:
Use the Up () or Down () arrow keys to change the Fail Stop setting, then press the
SET key to advance to the next parameter or press the EXIT key to store the setting and
return to the test mode.
Fail Stop is a function that will stop a sequence of tests if a failure occurs. If this function
is turned OFF, the sequence of tests will continue to the end of the sequence regardless of
whether or not a failure has occurred. If the Fail Stop is ON and a failure occurs during
the test sequence, the red RESET button will light and a short alarm will sound but the
sequence will continue to the end. At the end of the test sequence, the red RESET button
will light and alarm will sound indicating failure during the sequence. Pressing the
RESET button will silence the alarm and reset the instrument.
10.4. Key Lock or Memory Lock setting
The model 6330 is equipped with two different levels of lockout selection. The first
selection is Key Lock. Within this selection, you can lockout all front panel control
functions except TEST and RESET. The second selection is Memory Lock and is used in
conjunction with the Key Lock. Within this selection, you can lockout all front panel
control functions except TEST, RESET and memory select.
Use the following chart to set the Key Lock and Memory Lock for your application.
TEST, RESET, and SET/Up-Down arrows
for memory selection
