OPERATION
48
10.6. DUT-HV Set setting
Press EXIT key once then press the SET key until the display shows:
Use the Up () or Down () arrow keys to change the DUT-HV setting, then press the
SET key to advance to the next parameter or press the EXIT key to store the setting and
return to the test mode.
The DUT-HV Set setting will enable or disable the DUT Output relay when an AC or DC
Hipot test or an Insulation Resistance test is performed. This is a global parameter and
must be enabled for high voltage to be present at the rear panel terminals during the test.
There is also a DUT OUTPUT ON setting in each test’s parameter menu that must be
enabled.
DUT-HV Setting = OFF
or
DUT-HV Setting = ON
