OPERATION
OPERATION INSTRUCTIONS FOR MODEL 6330
POWER UP
Check to be sure the correct input line voltage has been selected on the rear panel, either
115 volts AC or 230 volts AC. Connect the power input plug into its socket on the rear
panel of the instrument. Connect the male end of the plug to the outlet receptacle.
Be sure that the safety ground on the power line cord is not
defeated and that you are connecting to a grounded power source.
Connect the rear panel chassis ground for additional safety.
Turn on the POWER switch located on the lower left hand side of the front panel. Upon
powering the instrument up, a POWER ON SELF TEST (POST) will be automatically
performed. This test will check for the condition of the instrument’s critical components.
In addition the display will show the following message, with the actual model number
and software version number:
The instrument will recall the last memory program that was active and the display will
show the parameters that were programmed into that memory. The instrument is now
ready for operation.
SETUP PROCEDURE
1. Memory configuration
The model 6330 is equipped with 20 memory programs numbered 1 through 20. Each
memory location contains 10 separate steps that can be connected sequentially to the next
consecutive step. Only one test can be selected for each step.
To recall a memory program press the SET key, then press the Up () or Down () arrow
keys until the specific memory you wish to recall is displayed. Please see procedures
below for details. Pressing the EXIT key will activate selected memory position. To start
a test, press the TEST button.
