QUICK START
to a suitable known good ground before energizing this instrument and then connect the
return lead first (black) to the test fixture or item followed by the high voltage output lead.
f). Please check your connections to be sure they are making good contact and that the test
station or area is clear of debris and other personnel.
DO NOT TOUCH THE DEVICE UNDER TEST ONCE THE
TEST HAS BEEN STARTED.
To initiate the test press the green TEST button on the front panel. This is a momentary
button and does not need to be held in the pressed position during the test. The instrument
will then cycle ON and begin the test using the defaults. If a failure occurs, you will
HEAR an audible alarm. To stop the alarm you must depress the red button marked
RESET. This will silence the alarm and reset the instrument to begin another test. This
RESET button may also be used as a safety button to quickly ABORT a test and cut off the
HIGH VOLTAGE.
When HIGH VOLTAGE is present, a RED flashing indicator located above the
HV receptacle will remain flashing until the HIGH VOLTAGE is OFF. If the
device under test PASSED the test then no audible alarm will sound. You will
hear a brief BEEP to let you know the item was successfully tested and it
PASSED. In the case of a FAIL condition, the instrument will provide a memory of the
test condition results on the LCD display that will remain until the next test is initiated.
Depressing the RESET button will reset the instrument alarm while keeping the last test
results on the display. Depressing the RESET button a second time will clear the display.
