OPERATION
Note: The Delay timer in the Functional Run test mode differs from the Dwell timer in
the Hipot mode. A judgment is not made until the Delay time has elapsed. Therefore,
when the Delay time is set to zero Pass and Fail judgment or indications will not be
made.
8.7. To set the Dwell time
Press the SET key until the display shows:
Use the Up () or Down () arrow keys to enter the desired dwell time, then press the
SET key to advance to the next parameter or press the EXIT key to store the setting and
return to the test mode. If the dwell time is set to 0.0s, the instrument will operate in a
continuous ON mode when the TEST button is pressed. It will stop when the RESET
button is pressed or the DUT goes into failure. The actual minimum dwell time setting is
0.5 seconds. The maximum dwell time setting is 999.9 seconds. Any attempt to set the
value more than 999.9s or less than 0.0s will cause the instrument to indicate an ERROR
by producing two short beeps.
8.8. To set the Connect mode ON/OFF
Press the SET key until the display shows:
Press the Up () or Down () arrow keys to toggle the connect mode to ON or OFF, then
press the SET key to advance to the next parameter or press the EXIT key to store the
setting and return to the test mode. If Connect is set to ON the next step in the sequence
will be executed. If Connect is set to OFF the test sequence will stop at this step. If step
10 is set to ON the test process will be connected to the first step of the next memory.
Step 10 of the memory 20 does not have Connect ON/OFF option.
9. Line Leakage test mode setting
9.1. To set the HI and LO Limits (Voltage)
Press the SET key until the display shows:
Please use the Up () or Down () arrow keys to enter the desired value of the High or
Low Limits voltage trip point then press the SET key to advance to the next parameter or
press the EXIT key to store the setting and return to the test mode. The unit of measure is
0 – 277 VAC. Any attempt to set the value outside these limits will cause the instrument
to indicate an ERROR by producing two short beeps.
9.2. To set the HI and LO Limits (Leakage Current)
