OPERATION
3.4. If the resistance exceeds the metering range, the red RESET button will illuminate
and the alarm will be activate. The display will show:
If current
3.0 – 10.0A
If current
10.1 – 25.0A
If current
25.1 – 30.0A
To stop the alarm, press the RESET button once. The alarm will stop and the display will
retain the failure information. The instrument is now ready for the next test. If the RESET
button is pressed again, the failure information will be cleared and the display will
indicate the setting data of the test. The display will show:
3.5. If the resistance exceeds the high limit trip setting but does not exceed the metering
range, the red RESET button will illuminate and the alarm will be activated. The display
will show:
To stop the alarm, press the RESET button once. The alarm will stop and the display will
retain the failure information. The instrument is now ready for the next test. If the RESET
button is pressed again, the failure information will be cleared and the display will
indicate the setting data of the test.
3.6. If the resistance does not exceed the low limit setting, the red RESET button will
illuminate and the alarm will be activated. The display will show:
To stop the alarm, press the RESET button once. The alarm will stop and the display will
retain the failure information. The instrument is now ready for the next test. If the RESET
button is pressed again, the failure information will be cleared and the display will
indicate the setting data of the test.
4. Functional Run test mode
4.1. To initiate a test, press the TEST button on the front panel. The display will
immediately show:
X – X HI-Lmt XXX.Xs
XX.XA GND >510m
X – X HI-Lmt XXX.Xs
XX.XA GND >200m
X – X HI-Lmt XXX.Xs
XX.XA GND >150m
GND Set XXX.Xs
XX-XX XX.XA XXXmΩ
GND Hi-Limit XXX.Xs
XX-XX XX.XA XXXmΩ
GND LO-Limit XXX.Xs
XX-XX XX.XA XXXmΩ
