Page 280 (Model J)
Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
5 1 L0280/KV Pneumatic module assembly
(See Figure 1 for next highest assembly)
RF
5 N0280/75 .Tube, Polyurethane (Length 330mm) 1
10 N0280/75 .Tube, Polyurethane (Length 330mm) 1
15 N0280/75 .Tube, Polyurethane (Length 140mm) 1
20 N0280/75 .Tube, Polyurethane (Length 255mm) 1
25 N0280/75 .Tube, Polyurethane (Length 210mm) 1
30 N0280/75 .Tube, Polyurethane (Length 140mm) 1
35 N0280/75 .Tube, Polyurethane (Length 140mm) 1
40 N0280/75 .Tube, Polyurethane (Length 230mm) 1
45 N0280/75 .Tube, Polyurethane (Length 330mm) 1
50 N0280/75 .Tube, Polyurethane (Length 120mm) 1
55 N0280/40/01 .Tube connector, equal tee 1
60 N0280/40/01 .Tube connector, equal tee 1
65 N0280/75 .Tube, Polyurethane (Length 330mm) 1
70 N6642 .Tube connector, plugin reducer 1
75 N0280/75/01 .Tube, Polyurethane (Length 650mm) 1
80 M0434 .Cable tie 1
85 N6642 .Tube connector, plugin reducer 1
90 N0280/11/01 .Cover plate, Oxygen cell 1
95
T1270/01/UK/05
.Label, Oxygen cell cover plate
Part of the T1270/01/UK label set
1
100 N0280/11/02 .Screw, captive (M3 x 10mm) 2
105 N2191/10 .Oxygen sensor cell 1
1
110 N0280/02 .Manifold assembly, pressure regulators
(See items 150-175)
1
Attaching parts
115 H4091/03 ..Nut, self locking (M4) 4
120 H4093 ..Washer, plain (M4) 4
125 N0280/03 .Solenoid valve assembly, in line 1
To Next Page
