37.4 Data transferred to the VueLink system from the SLE5000
The RS232 interface to the VueLink monitor enables the SLE5000 to send
monitored patient data, ventilator settings, waveforms and alarms. Three digital
waveforms are transmittable to the VueLink system, which are Pressure (AWP),
Flow(AWF) and Tidal Volume(AWV). The sample rate for these waveforms is
8ms.
The following table lists the parameters that are transmitted to the VueLink
system:
ID Name Range Units Description SPI
Select-
able
(trend-
able)
View-
able in
Task
Window
1 sAWRR 0 to 150 rpm Set respiratory rate. This is the same as
the set BPM rate. In HFO only mode this
value is set to 0.
2 sInsTi 0.10 to 3.00 sec Set inspiratory time. Same as the set Ti. In
HFO only mode this value is set to 0.
3 sHFVRR 3.0 to 20.0 Hz Set high frequency ventilation respiratory
rate. This is the same as the set HFO rate.
In non-HFO modes, this value is set to 0.
4 AWRR 0 to 255 rpm Measured respiratory rate. Same as the
BPM total display except for HFO only
mode when it is set to 0.
5 PEEP -175 to 175 mbar This is the measured PEEP. In HFO only
mode it indicates the minimum pressure.
6 InstTi 0 to 12.75 sec Measured Inspiratory time. Same as the
measured Ti. In HFO mode only this is set
to 0.
7 TVex 0 to 999.9 ml Measured expiratory volume. Same as Vte
on the display. Only available with a flow
sensor.
8 PIP 0 to 175 mbar This is the measured PIP. In HFO only
mode it indicates the maximum pressure.
9 FIO_2 0 to 100 % This is the measured FiO
2
value.
10 TVin 0 to 999.9 ml Measured inspiratory volume. Only
available with a flow sensor.
11 HFVAm 0 to 175 mbar High frequency ventilation amplitude.
Measures the difference between
maximum and minimum HFO pressures.
12 MnAwP -175 to 175 mbar Measured Mean Airway Pressure
13 MV 0 to 99.99 l Measured minute volume. Only available
with a flow sensor.
14 Cdyn 0 to 25.5 ml/
mbar
Measured dynamic compliance. Same as
Compl. on the display. Only available with
a flow sensor. Set to zero in HFO modes.
