SLE SLE5000 Model J - Overview; Data and Pinout Description; Cable

(Model J) Page 323
36.3 Overview
36.4 Data and Pinout description.
36.4.1 Version 3.3
Data Format: RS232-C compatible, 9600 bps, 8 data bits, 1 stop bit, no parity. The data
output is a comma delimited ASCII text string terminated by carriage return and linefeed
(<CR>,<LF>). There is 1 second between the end of one text string transmission and the
beginning of the next.
36.4.2 Version 4.1 to 4.3.2
Data Format: RS232-C compatible,19200 bps, 8 data bits, 1 stop bit, no parity. The data
output is a comma delimited ASCII text string terminated by carriage return and linefeed
(<CR>,<LF>). There is 1 second between the end of one text string transmission and the
beginning of the next.
RS232 Pinout: The RS232 interface connector pin assignments are as follows;
36.5 Cable
This pin assignment allows the ventilator to be connected directly to the RS232-C serial port
on a PC with a standard serial cable.
Pin Signal
1DCD
2TXD
3RXD
4 DSR
5GND
6DTR
7CTS
8RTS
