SLE SLE5000 Model J - Electrical Safety Testing of the SLE5000; Electrical Safety Test Procedures

(Model J) Page 61
11. Electrical Safety Testing of the SLE5000
This test is performed using an approved electrical safety testing device.
The electrical safety test must be carried out on the unit with all the electrical connections
intact.
Connect the ventilator to the electrical safety tester and turn the unit ON.
Connect the flow sensor connector via a test loom to the electrical safety tester.
Perform the tests.
Equipment under test is: SLE5000 Infant Ventilator Class 1B (flow sensor is a Floating type
applied part).
Check that in all the preceding tests: the resistance to earth on the internal metal screening
is less than 0.2Ω.
Test Expected Results
Class B Tests
Expected Value Tolerance
Insulation Resistance
>200MΩ
Earth Continuity
<0.2Ω
Earth Leakage
0 μA +500 μA
Earth Leakage (supply o/c)
0 μA +1000 μA
Enclosure Leakage (normal)
0 μA +100 μA
Enclosure Leakage (earth o/c)
0 μA +500 μA
Enclosure Leakage (supply o/c)
0 μA +500 μA
Patient Leakage on Applied Part
0 μA +100 μA
Patient Leakage on Applied Part (Earth o/c)
0 μA +500 μA
Patient Leakage on Applied Part (supply o/c)
0 μA +500 μA
Class BF Tests
Mains on Applied Part Normal
0 μA +5000 μA
Mains on Applied Part Reversed
0 μA +5000 μA
