Page 32 (Model J)
6. Component Replacement Procedure
The component replacement procedures detailed in this chapter describes how to replace
the individual component in isolation. Each procedure details what setup is required to return
the ventilator to service. After completing any or all of the following procedures a full
functional test as described in this manual must be carried out.
The following replacement and setup procedures are detailed in this chapter.
Electronic unit
• Compact flash card................................... SLE Part Nº: N6631/21/CF/50
• PC board .................................................. SLE Part Nº: N6631/LX800
• CAN card .................................................. SLE Part Nº: N6634
• Computer /display control assembly......... SLE Part Nº: L0275/OEM2
• Serial controller (Touch screen) ................ SLE Part Nº: N6631/2216
• Control and monitor board ........................ SLE Part Nº: A0763/02/M
• Power supply unit...................................... SLE Part Nº: M0915
• Batteries.................................................... SLE Part Nº: M0901
• Transducer PCB assembly ....................... SLE Part Nº: A0761
• LCD........................................................... SLE Part Nº: N6631/02
• Touch screen............................................. SLE Part Nº: N6631/05
• Inverter PCB ............................................. SLE Part Nº: N6631/13
•
Pneumatic Unit
• Conical and Duckbill filters........................SLE Part Nº: N2185/06 & N2185/05
• Blender manifold block..............................SLE Part Nº: N0280/01
• Pressure regulators PR3, PR4 & PR6 ......SLE Part Nº: N0280/02/S46
• High speed jet valves SV9, 10, 11 & 12....SLE Part Nº: N0280/03
• Regulator input air PR1.............................SLE Part Nº: N0280/05
• Regulator input oxygen PR2.....................SLE Part Nº: N0280/06
•
