37.5 Alarm and inoperative indications
The VueLink display will show ventilator alarms and inoperative conditions.
Alarms and Inoperative conditions (inops) are displayed along the top of the
VueLink monitor screen.
The inops are shown in green at the top left of the screen, alarms are shown in
either yellow (mid top screen) or red (top right).
Red alarms indicate a life-threatening situation which requires an immediate
response from the medical staff and yellow alarms indicate a situation where the
medical staff are necessary but it is of less critical importance.
The textual alarm messages on the VueLink system are brief summaries of the
ventilator alarm conditions. The following table shows how the SLE5000
messages correspond to VueLink display messages.
VueLink Message Type
and text
Corresponding SLE
5000 Alarm conditions
(priority in brackets)
Notes
GREEN inop -
“VENT INOPERATIVE”
Monitor Failure (1)
Controller Failure (4)
Monitor Cksm Fail (5)
Controller Reset (6)
Monitor coms (23)
Isol sys fail (26)
Flow ADC fail (27)
User interface fail (33)
Fresh gas sol fail (42)
Mon/disp coms fail (49)
Alarm cont. fail (50)
Indicates one of 11 alarm
conditions has occurred. Refer to
the SLE5000 main display to
identify cause. All parameter
values are displayed as -?-
GREEN inop -
“NO FLOW SENSOR”
None The following parameter values
are displayed as -?-TVex
TVin
MV
Cdyn
Rdyn
Leak
C20/C
GREEN Inop - “FLOW
SENS. CALIB”
None Indicates that the flow sensor is
currently being calibrated.
GREEN Inop - “O2 CELL
FAIL”
O2 Cell Disconn (43)
O2 Cell Exhausted (45)
O2 Cell Cal Fail (46)
The parameter value for FIO_2 is
displayed as -?-
