Page 284 (Model J)
- Item Not illustrated
5 425 N0280/40/07 .Tube connector 1

430 N0280/09/04 . Connector, proximal airway 1
Attaching parts
435 H1091 ..Nut (M10) 1
440 H1094 ..Washer (M10) 1

445 N0280/40/07 .Tube connector 1

450 N0280/09/05 .Bracket, pressure regulators
(Issue 2)
1
Attaching parts
455 H4091/03 ..Nut, self locking (M4) 3
460 H4093 ..Washer, plain (M4) 3

465 N0280/09/06 .Block, fixing 6
Attaching parts
470 H4212 ..Screw (M4 x 12) 3

475 N0280/09 .Chassis, pneumatic unit 1

Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
