SLE SLE5000 Model J - Calibration Checklist: Pressure Calibration Verification

(Model J) Page 309
Item 16: Total Power Fail Alarm Test
Item 17: Pressure Calibration Verification
a) CPAP
b) CMV
c) HFO
Total power fail alarm test: Initial
PIP Setting Lower limit Actual reading Upper limit
0 mbar 0 mbar 1 mbar
5 mbar 4 mbar 6 mbar
10 mbar 9 mbar 11 mbar
15 mbar 14 mbar 16 mbar
20 mbar 19 mbar 21 mbar
PIP Setting Lower limit Actual reading Upper limit
10 mbar 9 mbar 11 mbar
20 mbar 19 mbar 21 mbar
30 mbar 29 mbar 31 mbar
40 mbar 39 mbar 41 mbar
50 mbar 49 mbar 51 mbar
60 mbar 59 mbar 61 mbar
Delta P setting Lower limit Actual reading Upper limit
min 0 mbar 1 mbar
40 mbar 0 mbar 2 mbar
80 mbar 0 mbar 2 mbar
120 mbar 0 mbar 4 mbar
160 mbar 0 mbar 5 mbar
max 0 mbar 12 mbar
