(Model J) Page 49
3.Remove the four nuts and washers (G)
securing the pressure regulator manifold
assembly.
4. To remove the pressure
regulators (H, I & J) from
the manifold block (K)
remove the screws (L),
two per regulator.
Note: that the ‘O’ rings (M) will be released once the regulator has been
removed.
5. Assembly is reversal of removal.
Setup: Full system calibration is required for this component.
