(Model J) Page 51
3. The high speed valve assembly and
loom (E) can now be removed by
disengaging the valves from the rear of
the forward and reverse jet manifold
(F).
4. Assembly is reversal of removal.
Setup: Pneumatic setup and full system calibration is required for this component.
