Snap-On VERUS User Manual

31
Scanner Operations Basic Operation and Navigation
Use the slider in the middle of the toolbar to quickly move through paused data.
Figure 4-11 Sample data buffer slider
Go To End Moves to the last frame in the data buffer
Clear Erases data in the data buffer
Step Back Moves to the previous frame in the data buffer
Frame Counter Indicates the data buffer frame currently displayed
Step Forward Moves to the next frame in the data buffer
Zoom In
Increases the magnification by decreasing the sweep
of the graph
Zoom Out
Decreases the magnification by increasing the
sweep of the graph
Table 4-2 Data buffer toolbar icons (sheet 2 of 2)
Name Icon Description

Snap-On VERUS Specifications

General

Manufacturer	Snap-On
Model	VERUS
Function	Diagnostics, Programming, and Analysis
Display	Touchscreen LCD
Connectivity	USB, Wi-Fi
Software Updates	Yes, via Wi-Fi
Power Source	AC Adapter
Compatibility	Various vehicle makes and models (check specifications for details)
