SolaX Power X3-IES Series - Electrical Connection Guide; 7.1 Battery Electrical Connection

80
Mechanical Installation
M5*14
2.2-2.5 N·m
Figure 6-47 Tightening M5 screws
NOTICE!
• Please make sure that the corners and edges of the BMS and battery modules are
aligned before tightening screws.
Step 13: Remove the dustproof cover from the bottom of the inverter.
Figure 6-48 Removing the dustproof coverr
