SolaX Power X3-IES Series User Manual

81
Mechanical Installation
Step 14: Install the inverter on the BMS.
Figure 6-49 Installing the inverter
NOTICE!
• At least two persons are required to move the inverter.
Step 15: Lock the screws on both sides of the inverter with the BMS.
M5 * 14
2±0.1 N·m
Figure 6-50 Locking the inverter with the BMS
