MPI-540 – USER MANUAL
102
The meter is ready for
measurement.
 Connect the meter to the tested
object.
 Measurement starts automati-
cally.
Read the measurement result.
The result is the arithmetic mean
of the values of two measure-
ments at a current of 200 mA with
opposite polarities R
F
and R
R
.
2
RF
RR
R


Signal lights for the limit
(step )
the result is within the set
limit
the result is outside the set
limit
assessment not possible
After selecting the bar on the
right side, a menu will slide out
with additional measurement re-
sults.
