R
F
– result obtained for a posi-
tive polarity of the measuring cur-
rent
R
R
– result obtained for a nega-
tive polarity of the measuring cur-
rent
Selecting the bar hides the
menu.
Save the measurement to the meter memory using the icon. A detailed description of
memory management is contained in section 5.1.3.
The last measurement can be recalled using the icon.
Press the START button in order
to start the next measurement
without disconnecting test leads
from the object and proceed to
step .
NOTE!
Display of symbols indicates that the tested object is live. The
measurement is blocked. The meter must be immediately disconnected from the
object.
If the Autozero option was not deselected, (steps ), the meter invariably
reduces the measurement result by the resistance of the connected test leads.
Then, for each change of the leads, the Autozero procedure must be repeated.
The correction factor is also remembered after restarting the function and/or the me-
ter.
If the test leads have been changed to such of a lower resistance than the previous
ones but the Autozero procedure has not been performed, the meter will under-
state the value of the measurement. In extreme cases, the meter may indicate a
negative resistance. Similarly, greater resistance of the leads causes an over-
stated result of the measurements.
Additional information displayed by the meter
The meter is ready for measurement.
Too high voltage on the tested object.
Interference voltage occurs on the tested object. The meas-
urement is possible however it will be burdened with addi-
tional uncertainty that is specified in the technical data.
