Sony CCD-TR317 - Page 10

— 10 —
E
E
E
E
Block
Function
61
61
62
62
Detailed
Code
00
10
00
01
Symptom/State
Difficult to adjust focus
(Cannot initialize focus.)
Zoom operations fault
(Cannot initialize zoom lens.)
Handshake correction function does not
work well. (With pitch angular velocity
sensor output stopped.)
Handshake correction function does not
work well. (With yaw angular velocity
sensor output stopped.)
Self-diagnosis Code
Repaired by:
Correction
Inspect the lens block focus reset sensor (Pin qs of CN551 of VC-
234 board) when focusing is performed when the control dial is
rotated in the focus manual mode and the focus motor drive circuit
(IC551 of VC-234 board) when the focusing is not performed.
Note: Use the remote commander RM-95 only for the model without the
focus dial.
Inspect the lens block zoom reset sensor (Pin qf of CN551 of VC-
234 board) when zooming is performed when the zoom lens is
operated and the zoom motor drive circuit (IC551 of VC-234 board)
when zooming is not performed.
Inspect pitch angular velocity sensor (SE451 of SE-101 board)
peripheral circuits.
Inspect yaw angular velocity sensor (SE452 of SE-101 board)
peripheral circuits.
