Sony CCD-TR317 - Waveforms

4-93
CCD-TR317/TR517/TRV17/TRV37/TRV47/
TRV57/TRV57P/TRV67/TRV87/TRV87P
WAVEFORMS
CD-239/240 BOARD
CAMERA REC
2 IC1201 3,4

3 IC1201 7

4 IC1201 qs“ 

0.6Vp-p
H
4.6Vp-p
105 nsec
5 IC1201 qd,qf¢
105 nsec
6.8Vp-p
H
0.6Vp-p
6 Q201 E

1 IC1201 1,2
6.8Vp-p
H
6.8Vp-p
H
VC-234 BOARD (1/13)
2 IC501 qa
CAMERA REC/PB
1 IC501 5
CAMERA REC/PB
3.6Vp-p
3.6Vp-p
1.2Vp-p
3 IC501 wa
CAMERA REC
6.0Vp-p
8.717 MHz
4 IC501 wh
CAMERA REC
H
6.8Vp-p
5 IC501 wk
CAMERA REC
H
6.8Vp-p
14.3181 MHz
28.63562 MHz
7 IC502 e;
CAMERA REC
6 IC502 qh
CAMERA REC/PB
LINE REC
H
3.2Vp-p
14.318 MHz
0.5Vp-p
8 IC502 ef
LINE REC
H
0.3Vp-p
9 IC502 eh PB
H
4-3. WAVEFORMS
