2-1
SECTION 2
DISASSEMBLY
CCD-TR317/TR517/TRV17/TRV37/TRV47/
TRV57/TRV57P/TRV67/TRV87/TRV87P
The following flow chart shows the disassembly procedure.
[Connection diagram for service position (Mainly for voltage measurement and check)]
MA-374/375, CF-66/67, CD-239/240, VL-29, PJ-99/100, SE-101, EJ-29/30, DD-134,
VC-234 boards, Mechanism deck-2
2-5. EVF block assembly
CCD-TR317/TR517
CCD-TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67/TRV87/TRV87P
2-8. Lens device, CD-239/240 board
2-9. DD-134, SE-101 boards
2-4. Mechanism deck-1
2-1. PD-117 board, Back light, Liquid crystal display panel
(TRV model)
TRV model
: CCD-TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67/TRV87/TRV87P
B/W EVF model
: CCD-TR317/TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67/TRV87/TRV87P
COLOR EVF model
: CCD-TR517
: CCD-TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67
TR model
: CCD-TR317/TR517
: CCD-TR317/TR517/TRV47
Super night shot model
: CCD-TRV87/TRV87P
Stereo model
: CCD-TRV87/TRV87P
TRV night shot model
: CCD-TRV17/TRV37/TRV57/TRV57P/TRV67/TRV87/TRV87P
Video light model
No video light model
2-2. Front panel assembly, MA-374/375 board
Mechanism deck service position-1
PD-117 board service position
MA-374/375 board service position
2-3. Cabinet (R) block assembly
2-10. VC-234, EJ-29/30 boards, Mechanism deck-2
2-11. CF-66 board, Liquid crystal display panel (TR model)
(TR model)
(TRV model)
(TRV model)
2-12. CF-67 board, Speaker, Push switch (TRV model)
2-13. LCD block assembly, Hinge assembly (TRV model)
2-14. Harness processing of the hinge assembly (TRV model)
MA-374/375, CF-66/67, CD-239/240 boards
service position
2-6. VF-129 board
(B/W EVF model)
VF-129, MA-374/375, CF-66/67
CD-239/240 boards service position
2-7. VF-141, LB-62 boards
(COLOR EVF MODEL)
VF-141, LB-62, MA-374, CF-66,
CD-239 boards service position
Note : Use the parts only which can be removed
easily from outside of the mechanism deck.
B/W EVF model
COLOR EVF model
