5-24
7. Auto White Balance & LV Standard Data Input
Subject Clear chart
(Color reproduction adjustment frame)
Adjustment Page F
Adjustment Address 3C to 41
Note1: This adjustment should be carried out upon completion of “6. Color
Reproduction Adjustment”.
Note2: Check that the data of page: 6, address: 02 is “00”. If not, turn off
the power and turn on again.
Switch setting:
1) NIGHT SHOT ..................................................................OFF
2) DIGITAL ZOOM (Menu display) ...................................OFF
3) STEADY SHOT (Menu display) .....................................OFF
4) VIDEO LIGHT ................................................................OFF
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 6, address: 01, set data: 11, and press the PAUSE
button of the adjustment remote commander.
3) Select page: 6, address: 01, set data: 0D, and press the PAUSE
button.
(When the standard data is take in, the data will be automatically
input to page: F, address: 3C to 41.)
4) Select page: 6, address: 02, and check that the data is “01”.
Processing after Completing Adjustments
1) Select page: 6, address: 01, set data: 00, and press the PAUSE
button of the adjustment remote commander.
2) Select page: 0, address: 01, and set data: 00.
3) Perform “Auto White Balance Adjustment”.
To Next Page
