Sony CCD-TR317 - Mechanism Deck-1

2-5
2-4. MECHANISM DECK-1
VC-234
MA-
B
o
a
rd
B
C
D
A
A
qg Cabinet (L) assembly
Cabinet (R) block assembly
AC POWER
ADAPTOR
FP-43 flexible board
(20P)
AC IN
Adjustment remote
commander (RM-95
)
DC IN
Remove it in the
direction of the arrow
B .
Remove it gently as a
thin FP-49 flexible board
(Super night shot model)
is held by a claw.
qf Jack cover
5 Screw (M2 × 4),
lock ace, p2
qa Control switch block
(SS-9700)
Control switch block
(SS-9700)
1 Two screws
(M2
× 3),
lock ace, p2
8 Screw
(M2
× 3)
qs Two screws
(M2
× 3)
Two screws
qd Claw and
Dowel
q; Claw
Claw
Dowel
qh Two screws
(M2
× 3)
qj MD frame (B)
2 Cassette lid assembly
4 Screw
(M2
× 4),
lock ace, p2
3 Screw
6 Battery panel block assembl
y
Claw
[MECHANISM DECK SERVICE POSITION-1]
• How to move up the cassette
compartment manually
Press the cassette compartment
in the direction of the arrow
C
to move it up in the direction of
the arrow
D .
7 FP-49 flexible board (6P)
(Super night shot model)
9 Two tapping
screws
(B2 × 5)
CPC-7 jig
(J-6082-382-A)
Note: Use the parts only which can be removed easily from outside of the mechanism deck.
LANC jack
Front panel block assembly
DP-78 harness
(TRV model)
DP-78 harness
(TRV model)
