5-62
6. Record of Use check
Page 2 Address A2 to AA
Using method:
1) The record of use data is displayed at page: 2, addresses: A2 to
AA.
Note: This data will be erased when the coin lithium battery (CF-66/
67 board BH001) is removed (reset).
7. Switch check (1)
Page 2 Address 43
Note: CCD-TRV87/TRV87P model only.
Using method:
1) Select page: 2, address: 43.
2) By discriminating the bit value of display data, the state of the
switches can be discriminated.
Bit
A2
A3
A4
A5
A6
A7
A8
A9
AA
Function
Drum rotation Hour (H)
counted time Hour (L)
(BCD code) Minute
User initial power Year
on date Month
(BCD code) Day
Final condensation Year
occurrence date Month
(BCD code) Day
Remarks
1000th place digit and 100th place digit of counted time (decimal digit)
10th place digit and 1st place digit of counted time (decimal digit)
After setting the clock, set the date of power on next
Bit
0
1
2
3
4
5
6
7
Function
VTR MODE SW (MA-374/375 board S302)
CAM MODE SW (MA-374/375 board S303)
START/STOP SW (SS-8500 block S002)
EJECT SW (SS-8500 block S003)
CC DOWN SW (Mechanism chassis)
PHOTO FREEEZE SW (FP-49 flexible)(Note)
When bit value = 1
OFF
OFF
OFF
OFF
OFF (UP)
OFF
When bit value = 0
ON
ON
ON
ON
ON (DOWN)
ON
