6-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND: Canadian model
KR: Korea model
HK: Hong Kong model
JE: Tourist model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
CD-239
A-7074-161-A CD-239 BOARD, COMPLETE (TR317/TR517)
***********************************
(Ref.No.;1000 Series)
(IC201 is not included in this complete board.)
< CAPACITOR >
C201 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
C204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C205 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V
< CONNECTOR >
CN201 1-573-354-11 CONNECTOR, FFC/FPC 14P
< COIL >
L201 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q201 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R201 1-216-797-11 METAL CHIP 10 5% 1/16W
R202 1-216-809-11 METAL CHIP 100 5% 1/16W
R203 1-216-833-91 RES-CHIP 10K 5% 1/16W
************************************************************
A-7074-148-A CD-240 BOARD, COMPLETE
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
**************************************
(Ref.No.;1000 Series)
(IC201 is not included in this complete board.)
< CAPACITOR >
C201 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
C204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C205 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V
< CONNECTOR >
CN201 1-573-354-11 CONNECTOR, FFC/FPC 14P
< COIL >
L201 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q201 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R201 1-216-797-11 METAL CHIP 10 5% 1/16W
R202 1-216-809-11 METAL CHIP 100 5% 1/16W
R203 1-216-833-91 RES-CHIP 10K 5% 1/16W
************************************************************
A-7074-152-A CF-66 BOARD, COMPLETE (TR317)
****************************
A-7074-156-A CF-66 BOARD, COMPLETE (TR517)
****************************
(Ref.No.;1000 Series)
< BATTERY HOLDER >
BH001 1-550-104-11 HOLDER, BATTERY
< BUZZER >
BZ002 1-529-104-21 BUZZER, PIEZOELECTRIC
< CAPACITOR >
C003 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C004 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
(TR317)
C004 1-119-661-11 TANTAL. CHIP 33uF 20% 6.3V
(TR517)
< CONNECTOR >
CN001 1-785-760-11 CONNECTOR, FFC/FPC (ZIF) 45P
CN002 1-774-765-11 CONNECTOR, FFC/FPC 8P
CN006 1-779-334-11 CONNECTOR, FFC/FPC 20P (TR517)
* CN007 1-778-283-11 CONNECTOR, FFC/FPC 4P (TR317)
CN010 1-691-364-21 CONNECTOR, FFC/FPC (ZIF) 26P
< DIODE >
D002 8-719-421-27 DIODE MA728-(K8).S0
D005 8-719-073-03 DIODE MA8082-(K8).S0
D006 8-719-073-03 DIODE MA8082-(K8).S0
D008 8-719-073-01 DIODE MA111-TX
< IC >
IC001 8-759-573-02 IC BU9735K-E2
Be sure to read “Precautions upon replacing CCD imager”
on page 4-8 when changing the CCD imager.
