6-13
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< COIL >
L001 1-216-295-91 SHORT 0 (TR517)
L002 1-216-295-91 SHORT 0 (TR517)
L003 1-216-295-91 SHORT 0 (TR517)
L004 1-469-527-91 INDUCTOR 47uH
L005 1-469-527-91 INDUCTOR 47uH
< TRANSISTOR >
Q001 8-729-402-42 TRANSISTOR UN5213-TX(TR317)
< RESISTOR >
R001 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR517)
R005 1-216-833-91 RES-CHIP 10K 5% 1/16W
R006 1-216-833-91 RES-CHIP 10K 5% 1/16W
R007 1-216-833-91 RES-CHIP 10K 5% 1/16W
R008 1-216-833-91 RES-CHIP 10K 5% 1/16W
R011 1-216-855-11 METAL CHIP 680K 5% 1/16W
R012 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R013 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R014 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R015 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R016 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R017 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R018 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R019 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R020 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R021 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R023 1-216-834-11 METAL CHIP 12K 5% 1/16W
R025 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R028 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR517)
R032 1-216-838-11 METAL CHIP 27K 5% 1/16W
R044 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR517)
R045 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR517)
R046 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR517)
R047 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR517)
R048 1-216-864-11 METAL CHIP 0 5% 1/16W
(TR317)
< SWITCH >
S002 1-771-138-61 SWITCH, KEY BOARD (DATE)
S005 1-771-138-61 SWITCH, KEY BOARD (COUNTER RESET)
S006 1-771-029-21 SWITCH, TACTILE (MENU) (TR317/TR517)
S007 1-771-029-21 SWITCH, TACTILE (EXPOSURE)
S008 1-771-025-41 SWITCH, ROTARY (SEL/PUSH EXEC)
(TR317/TR517)
S009 1-771-138-61 SWITCH, KEY BOARD (BACK LIGHT)
(TR317/TR517)
S010 1-771-138-61 SWITCH, KEY BOARD (TITLE) (TR317/TR517)
S011 1-771-138-61 SWITCH, KEY BOARD (TIME)
S012 1-771-138-61 SWITCH, KEY BOARD (FADER)
S014 1-771-138-61 SWITCH, KEY BOARD (PROGRAM AE)
S015 1-771-138-61 SWITCH, KEY BOARD (PICTURE EFFECT)
(TR317/TR517)
************************************************************
A-7074-126-A CF-67 BOARD, COMPLETE (TRV87/TRV87P)
***********************************
A-7074-120-A CF-67 BOARD, COMPLETE
(TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67)
**************************************
(Ref.No.;1000 Series)
< BATTERY HOLDER >
BH001 1-550-104-11 HOLDER, BATTERY
< CAPACITOR >
C001 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C004 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
< CONNECTOR >
CN001 1-785-760-21 CONNECTOR, FFC/FPC (ZIF) 45P
CN002 1-566-540-11 CONNECTOR, FPC (NON ZIF) 8P
* CN003 1-580-055-21 PIN, CONNECTOR (SMD) 2P
CN004 1-779-064-11 PIN, CONNECTOR (PC BOARD) 12P
CN005 1-778-508-21 PIN, CONNECTOR (PC BOARD) 6P
CN007 1-778-283-11 CONNECTOR, FFC/FPC 4P
CN008 1-766-644-21 CONNECTOR, FFC/FPC 8P (TRV87/TRV87P)
CN008 1-774-633-11 CONNECTOR, FFC/FPC 8P (TRV87/TRV87P)
* CN009 1-580-055-21 PIN, CONNECTOR (SMD) 2P
< DIODE >
D002 8-719-062-16 DIODE 01ZA8.2(TPL3)
D008 8-719-421-27 DIODE MA728-(K8).S0
D009 8-719-073-01 DIODE MA111-TX
< TRANSISTOR >
Q001 8-729-402-42 TRANSISTOR UN5213-TX
Q002 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
(TRV87/TRV87P)
Q003 8-729-230-72 TRANSISTOR 2SA1362-YG-EL
(TRV87/TRV87P)
< RESISTOR >
R002 1-216-833-91 RES-CHIP 10K 5% 1/16W
R003 1-216-833-91 RES-CHIP 10K 5% 1/16W
R004 1-216-833-91 RES-CHIP 10K 5% 1/16W
R005 1-216-833-91 RES-CHIP 10K 5% 1/16W
R006 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R007 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R008 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R009 1-216-849-11 METAL CHIP 220K 5% 1/16W
(TRV87/TRV87P)
R010 1-216-833-91 RES-CHIP 10K 5% 1/16W
(TRV87/TRV87P)
R011 1-216-853-11 METAL CHIP 470K 5% 1/16W
(TRV87/TRV87P)
R012 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R013 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R014 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R015 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TRV87/TRV87P)
R016 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(TRV87/TRV87P)
CF-66 CF-67
To Next Page
