Sony CCD-TR317 - Board, Back Light, Liquid Crystal; Display Panel (Trv Model)

2-2
NOTE: Follow the disassembly procedure in the numerical order given.
2-1. PD-117 BOARD, BACK LIGHT, LIQUID CRYSTAL DISPLAY PANEL (TRV MODEL)
PD
-117
PD
-117
1 Two screws
(M2
× 4),
lock ace, p2
1 Five claws
6 Four claws
5 Indication LCD
block assembly
8 Back light
7
7
Two tapping screw
s
(B2 × 7)
2 Two tapping screws
(B2
× 5)
q; Screw
(M2
× 3)
3 Two claws
5 Three claws
qa Two claws
8 Two claws
qs Panel frame (93)
9 P cabinet (M)(93)
assembly
qd Liquid crystal
indicator module
Liquid crystal
indicator module
qf Back light
Cold cathode
fluorescent tube
qg PD-117 board
6
Adjustment
remote commander
(RM-95)
LANC
jack
AC POWER
ADAPTOR
AC IN
Multi CPC jig
(J-6082-311-A)
Back light
Cold cathode
fluorescent tube
PD-117 board
CN5502
[PD-117 BOARD SERVICE POSITION]
4 P cabinet (C)(98)
Indication LCD block assembly
(Super night shot model)
3 Remove the
two solderings
4 Remove the
two solderings
2 LCD
holder (93)
1 Four claws
Liquid crystal display panel
2 LCD
holder (98)
3 Liquid crystal
display panel
Liquid crystal display panel
(TRV night shot model)
REMOVING THE BACK LIGHT
REMOVING THE
LIQUID CRYSTAL DISPLAY PANEL
(SUPER NIGHT SHOT MODEL)
(TRV NIGHT SHOT MODEL)
(PRECAUTION DURING INSTALLATION)
FP-155 flexible
board
