Sony CCD-TR317 - Switch Check (2); Headphone Jack Check (TRV Model Only)

5-63E
Address
60
(KEY AD0)
(IC803 od)
61
(KEY AD1)
(IC803 of)
62
(KEY AD2)
(IC803 og)
64
(KEY AD4)
(IC803 oj)
65
(KEY AD5)
(IC803 ok)
66
(KEY AD6)
(IC803 ol)
00 to 0B
LASER LINK
(FK-8500 block)
(S008) Note2
PHOTO REC
(FP-49 flexible)
Note2
DIGITAL EFFECT
(CF-66/67 board)
(S001) Note2
DATE
(CF-66/67 board)
(S002)
PROGRAM AE
(CF-66/67 board)
(S003 (Note4))
(S014 (Note5))
0C to 23
STOP
(FK-8500 block)
(S001)
PAUSE
(FK-8500 block)
(S002)
PICTURE EFFECT
(CF-66/67 board)
(S016/004)
COUNTER RESET
(CF-66/67 board)
(S005)
BRIGHT(+)
(PD-117 board)
(S5701)
24 to 3E
FF
(FK-8500 block)
(S003)
REW
(FK-8500 block)
(S004)
MENU
(CF-66/67 board)
(S006)
EXPOSURE
(CF-66/67 board)
(S007)
END SEARCH
(CF-67 board)
(S008) Note3
BRIGHT(–)
(PD-117 board)
(S5702)
3F to 5C
REC
(FK-8500 block)
(S005, 007) Note2
PLAY
(FK-8500 block)
(S006)
EXECUTE
(CF-66/67 board)
(S008/009)
BACK LIGHT
(CF-66/67 board)
(S009/010)
TITLE
(CF-66/67 board)
(S010/011)
VOLUME(+)
(PD-117 board)
(S5703)
5D to 80
EDIT SEARCH(+)
(FK-8500 block)
(S009)
TIME
(CF-66/67 board)
(S011/012)
FADER
(CF-66/67 board)
(S012/013)
DISPLAY
(CF-67 board)
(S014) Note3
VOLUME(–)
(PD-117 board)
(S5704)
81 to A9
EDIT SEARCH(–)
(FK-8500 block)
(S010)
FOCUS INFINITY
(MR-8500 block)
(S001)
SUPER
NIGHT SHOT
(FP-62 flexible)
Note2
PANEL
REVERSE
(FP-152 flexible)
Data
AA to D6
FOCUS AUTO
(MR-8500 block)
(S001)
PANEL
CLOSE
D7 to FF
No key input
No key input
No key input
FOCUS MANUAL
(MR-8500 block)
(S001)
PANEL
OPEN
PANEL
NORMAL
(FP-152 flexible)
Bit
1
Function
Headphone jack
When bit value = 1
Headphone jack is used
When bit value = 0
8. Switch check (2)
Page 2 Address 60 to 66
Using method:
1) Select page: 2, address: 60 to 66.
2) By discriminating the display data, the pressed key can be
discriminated.
Note1: TR model / TRV model
TR model: CCD-TR317/TR517
TRV model: CCD-TRV17/TRV37/TRV47/TRV57/TRV57P/TRV67/TRV87/TRV87P
Note2: CCD-TRV87/TRV87P model only
Note3: TRV model only
Note4: Except CCD-TR317/TR517 model
Note5: CCD-TR317/TR517 model only
9. Headphone jack check
(TRV model only)
Page 2 Address 45
Using method:
1) Select page: 2, address: 45.
2) By discriminating the bit value of display data, the state of the
headphone jack can be discriminated.
