Sony CCD-TR317 - White Balance Adjustment (VF-141 Board)

5-30
6. White Balance Adjustment (VF-141 board)
Correct the white balance.
If deviated, the reproduction of the EVF screen may degenerate.
Mode Camera
Subject Arbitrary
Measurement Point Check on EVF screen
Measuring Instrument
Adjustment Page 7
Adjustment Address DA, DB
Specified Value The EVF screen should not be colored.
Adjusting method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 7, address: DA and DB, set the data to the initial
value.
Note: To write in the non-volatile memory (EEPROM), press the
PAUSE button of the adjustment remote commander each time
to set the data.
3) Check that the EVF screen is not colored. If colored, change
the data of page: 7, address: DA and DB so that the EVF screen
is not colored.
Note: To write in the non-volatile memory (EEPROM), press the
PAUSE button of the adjustment remote commander each time
to set the data.
4) Select page: 0, address: 01, and set data: 00.
Address
Data
DA
8D
DB
83
