Sony CCD-TR317 - Boards (Color Evf Model)

2-8
2-7. VF-141, LB-62 BOARDS (COLOR EVF MODEL)
1 Harness guide (C) (97)
3 VF base (C) (97)
5 Slide fixed
base (C) (97)
7 Two screws
(M2 × 3)
lock ace, p2
6 Electrostatic
sheet (97)
9 Claw
qa Slide base
(C) (97)
assembly
q; FP-151 flexible board
6 FP-151
flexible board
1 FP-151
flexible board (6P)
2 FP-151
flexible board (18P)
3 LCD (LCX0032-AK-J) (16P)
q; LCD (LCX0032-AK-J)
5 Three claws
qs
A
2 Two tapping
screws (B2 × 5)
4 Two tapping
screws
(B2 × 5)
3 EVF cabinet
(rear) (C) (97)
assembly
8
7 Three claws
9
4
VF-141 board
6 LB-62 board
7 LCD cushion (2) (97)
qa LCD cushion (1) (97)
qs Panel flexible cushion
qd VF lens (C) (97) assembly
9 LCD cushion (2) (97)
8 BL illuminator (97)
5 EVF cabinet
(upper C) (92)
4 Remove the slide
fixed base (C) (97)
by sliding it in the
arrow direction A .
8 Remove the harness
retainer from FP-151
flexible board
2 Screw (M2 × 3)
lock ace, p2
1 Turn the lever
in the direction
of the arrow.
REMOVING THE VF-141, LB-62 BOARDS
