6-14
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R017 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R018 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R019 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R020 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R021 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R022 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R026 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R027 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R034 1-216-838-11 METAL CHIP 27K 5% 1/16W
R036 1-216-838-11 METAL CHIP 27K 5% 1/16W
R043 1-216-864-11 METAL CHIP 0 5% 1/16W
R048 1-216-864-11 METAL CHIP 0 5% 1/16W
< SWITCH >
S001 1-771-138-61 SWITCH, KEY BOARD (DIGITAL EFFECT)
(TRV87/TRV87P)
S002 1-771-138-61 SWITCH, KEY BOARD (DATE)
S003 1-771-029-21 SWITCH, TACTILE (PROGRAM AE)
S004 1-771-138-61 SWITCH, KEY BOARD (PICTURE EFFECT)
S005 1-771-138-61 SWITCH, KEY BOARD (COUNTER RESET)
S006 1-771-138-61 SWITCH, KEY BOARD (MENU)
S007 1-771-029-21 SWITCH, TACTILE (EXPOSURE)
S008 1-771-138-61 SWITCH, KEY BOARD (END SEARCH)
S009 1-771-025-41 SWITCH, ROTARY (ENCODER)
S010 1-771-029-21 SWITCH, TACTILE (BACK LIGHT)
S011 1-771-138-61 SWITCH, KEY BOARD (TIME)
S012 1-771-138-61 SWITCH, KEY BOARD (FADER)
S013 1-771-029-31 SWITCH, TACTILE (FADER)
S014 1-771-138-61 SWITCH, KEY BOARD (PROGRAM AE)
************************************************************
A-7074-151-A DD-134 BOARD, COMPLETE (TR317)
*****************************
A-7074-155-A DD-134 BOARD, COMPLETE (TR517)
*****************************
A-7074-119-A DD-134 BOARD, COMPLETE
(TRV17/TRV37/TRV57/TRV57P/TRV67)
**************************************
A-7074-125-A DD-134 BOARD, COMPLETE (TRV87/TRV87P)
************************************
A-7074-113-A DD-134 BOARD, COMPLETE (TRV47)
*****************************
(Ref.No.;1000 Series)
< CAPACITOR >
C301 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C302 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C303 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C304 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C305 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C308 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C309 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C310 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C311 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C312 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C313 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C314 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C315 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C316 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C317 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C318 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C321 1-113-991-11 TANTAL. CHIP 33uF 20% 16V
C323 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C324 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C325 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C326 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C327 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C328 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C329 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C330 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C332 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C333 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C335 1-162-974-11 CERAMIC CHIP 0.01uF 50V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C336 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C337 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C338 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C339 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C340 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C341 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C342 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C343 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C344 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C345 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C346 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C347 1-119-749-11 TANTAL. CHIP 33uF 20% 4V
C348 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C349 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(TR517/TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C350 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C351 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C352 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C353 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C354 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C355 1-125-822-11 TANTALUM 10uF 20% 10V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C356 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C358 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C360 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C361 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C362 1-164-346-11 CERAMIC CHIP 1uF 16V
(TR517)
C363 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(TRV17/TRV37/TRV47/TRV57/TRV57P/
TRV67/TRV87/TRV87P)
C364 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C366 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C367 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CF-67 DD-134
